4-18m self propelled electric mobile scissor lift platform

Product name : Electri scissor lift platform

Main characteristics : The product has the characteristics of stable structure, low failure rate, reliable operation, safety and high efficiency, and simple and convenient maintenance.

Application : The electric scissor lift platform is mainly used in the production line of the logistics industry; lifting, loading and unloading of goods between the basement and the floor; it can also be used for lifting the stage, lifting the operation table; feeding the feeder at a high place; lifting parts when assembling large equipment ; loading and unloading of large machine tools and other moving vehicles for fast loading and unloading of goods.

Send Inquiry Now

4-18m self propelled electric mobile scissor lift platform

Product Details

Model	Platform(mm)	Net elevation(m)	Loda(kg)	Self weight(kg)	Dimensions(mm)
ADYD/FZ0.5-4	2010*930	4	500	850	201611001100
ADYD/FZ0.5-6	2010*930	6	500	950	201611001295
ADYD/FZ0.5-7	2010*930	6.8	500	950	201611001415
ADYD/FZ0.5-8	2010*930	8	500	1070	201611001535
ADYD/FZ0.5-9	2010*930	9	500	1170	201611001540
ADYD/FZ0.5-10	2010*1130	10	500	1360	201612901540
ADYD/FZ0.5-11	2010*1130	11	300	1480	201612901660
ADYD/FZ0.5-12	2462*1210	12	500	1950	246513601780
ADYD/FZ0.5-14	2845*1420	14	500	2580	284516201895
ADYD/FZ0.3-16	2845*1420	16	300	2780	284516202055
ADYD/FZ0.3-18	3700*1628	18	300	3900	370016281950

Classification

Scissor lift platform is divided into: mobile, fixed, traction. The lifting power of the mobile platform is manual or electric, the product structure is stable, the movement is flexible, the lifting is stable, the operation is convenient, and the load capacity is large.
