5tons car lift loading and unloading Fixed hydraulic scissor platform lifter
Fixed
lift platform is a kind of cargo lifting equipment with good lifting stability
and wide applications. It is mainly used for the transportation of goods between
the height difference of the production line; the on-line and off-line of
materials; the adjustment of the height of the workpiece when the workpiece is
assembled; the feeding of the high-altitude feeder; large-scale equipment
Lifting of components during assembly; loading and unloading of large-scale
machine tools; storage and loading and unloading sites are matched with
forklifts and other handling vehicles for fast loading and unloading of goods,
etc. According to the requirements of use, the auxiliary devices can be
configured and combined in any way, such as the safety protection device of the
fixed lifting platform; the electrical control method; the form of the working
platform; the form of power, etc. The correct selection of various
configurations can maximize the function of the lifting platform and achieve the
best use effect.

Model |
Load
Capacity |
Platform
Size |
Travel
Height |
Min.Height |
Power |
ADL3-3 |
3000kg |
5000x2500mm |
3000mm |
650mm |
5.5kw |
ADL3-4 |
3000kg |
5000x2500mm |
4000mm |
800mm |
5.5kw |
ADL3-6 |
3000kg |
5000x2500mm |
6000mm |
800mm |
7.5kw |
ADL5-3 |
5000kg |
6500x2600mm |
3000mm |
680mm |
7.5kw |
ADL5-4 |
5000kg |
6500x2600mm |
4000mm |
680mm |
7.5kw |
Note: our
car lifts can be customized to your different requirement. |
