ADYD/QX0.5-14 14M Scissor Lifting Platform 4-18 meter scissor lift table

Lift Mechanism : Scissor Lift

Lift Drive : Electric Motor

model : ADYD/QX0.5-14

Platform size : 2845*1420mm

Load capacity : 500kg

Overall Dimension : 2845*1620*1895mm

Send Inquiry Now

ADYD/QX0.5-14 14M Scissor Lifting Platform 4-18 meter scissor lift table

Product Details

The scissor-type lifting platform structure makes the lifting of the platform more stable, and the wide working platform and large carrying capacity make the range of high-altitude work larger and suitable for multiple people to work at the same time.

It makes aerial work more efficient and safer!

Product Features

● Electric hoisting, electric walking after lowering.

● Scissor design, safe and stable.

● Used for high-altitude maintenance of hotels, factories and office buildings.

● Standard does not include an extension platform, if you need an extension platform, you can add it.

Technical Parameter

Type	Platform(mm)	Net elevation(m)	Load(kg)	Self weight(kg)	Overall dimension(mm)
ADYD/QX0.5-4	2010x930	4	500	850	2016x1100x1100
ADYD/QX0.5-6	2010x930	6	500	950	2016x1100x1295
ADYD/QX0.5-7	2010x930	6.8	500	950	2016x1100x1295
ADYD/QX0.5-8	2010x930	8	500	1070	2016x1100x1415
ADYD/QX0.5-9	2010x930	9	500	1170	2016x1100x1535
ADYD/QX0.5-10	2010x1130	10	500	1360	2016x1290x1540
ADYD/QX0.5-11	2010x1130	11	300	1480	2016x1290x1660
ADYD/QX0.5-12	2462x1210	12	500	1950	2465x1360x1780
ADYD/QX0.5-14	2845x1420	14	500	2580	2845x1620x1895
ADYD/QX0.3-16	2845x1420	16	300	2780	2845x1620x2055
ADYD/QX0.3-18	3700x1628	18	300	3900	3700x1628x195
