Type : Double Mast Aluminum Alloy Lift Ladders Table Aerial Work Platform
Model : ADYD/AL12-200M2
Platform height max. : 12m
Platform operation height max. : 13.7m
Load capacity : 200kg
Platform size : 1450*600mm
Power : 1.5kw
Aluminum alloy type lifting platform used high strength and high quality aluminum alloy material, with the advantages of beautiful appearance, small size, light weight, lifting balance, safe and reliable, itself with wearing steel safety wire rope and safety protection device. Can operate up and down easily, widely used in factories, hotels, restaurants, airports, stations, theaters, exhibition hall and other places.
Product Features
1. High strength aluminum alloy casting high density support legs
2. Anti-wearing polyurethane wheels
3. Safety stainless steel guardrail
4. Safety emergency drop valve
5. Stable & safe aviation aluminum
6. Integrated distribution box, equipped with two remote controls
Technical Parameter
| Model | ADYD/AL12-200M2 |
| Platform height(m) | 12 |
| Platform operation height(m) | 13.7 |
| Load capcity （kg） | 200 |
| Platform size (mm) | 1450*600 |
| Supply voltage (v) | AC220/50HZ |
| Power (kw) | 1.5 |
| Weigh (kg) | 700 |
| Dimension (mm) | 1660*970*2000 |
