CE ISO electric scaffolding mobile manual scissor lift platform

Product name : Scaffolding mobile manual scissor lift platform

Model : ADYD/QL0.3-18

Platform size : 3070mm*1600mm

Loading : 300kg

Lifted height : 18m

Dimension : 3320mm*1810mm*2080mm

Weight : 3900kg

Send Inquiry Now

CE ISO electric scaffolding mobile manual scissor lift platform

Product Details

Mobile scissor lift are used where big lifting capability is required. With working heights up to 66ft and capabilities up to 1000kg, they are designed to provide larger platform work areas and generally to allow heavier loads than boom lift.

Features

　　-Vertical raising of platform

　　-Convenient operation (can be controlled both on the platform and the ground)

　　-Horizontal extension of deck(customized)

　　-Scissor lifts are available in various electric and battery and diesel powered models.

Technical parameters

Model	Platform size	Load(kg)	Lifted height(m)	Dimension(mm)	Weight(kg)
ADYD/QL0.5-4	2100mm*830mm	500	4	22509501200	880
ADYD/QL0.5-6	2100mm*830mm	500	6	22509501200	880
ADYD/QL0.5-7	2100mm*830mm	500	6.8	22509501280	970
ADYD/QL0.5-8	2100mm*930mm	500	8	225010601380	1050
ADYD/QL0.5-9	2100mm*930mm	500	9	225010601500	1165
ADYD/QL0.5-10	2100mm*1230mm	500	10	225013501530	1360
ADYD/QL0.5-11	2100mm*1230mm	300	11	225013501650	1400
ADYD/QL0.5-12	2550mm*1530mm	500	12	279616701750	2260
ADYD/QL0.5-14	2812mm*1530mm	500	14	306717301810	2486
ADYD/QL0.3-16	2812mm*1600mm	300	16	306718102080	3063
ADYD/QL0.3-18	3070mm*1600mm	300	18	332118102080	3900

Application places

Installation, maintenance and cleaning of high-altitude equipment such as construction sites, factories, warehouses, grain depots, stations, hotels, airports, docks, gas stations, sports factories, elevated pipelines, etc.; it can also be used for maintenance of lifting equipment, maintenance of field power facilities, steel Frame structure plant maintenance, etc.
